Tower Site Survey Checklist

Pre-Deployment Assessment Procedures

Comprehensive checklist for conducting telecom tower site surveys including structural, electrical, and RF assessments.

20 min read8 ChaptersUpdated: December 2024By: HNL Engineering Team

Disclaimer

This guide shares industry best practices for educational purposes. Actual engineering procedures follow project-specific protocols, SOPs, and terms agreed upon between HNL and the client. Site conditions, regulatory requirements, and equipment specifications may require deviations from these general guidelines. Always consult with qualified engineers before implementation.

1. Survey Overview

This technical guide provides comprehensive procedures for conducting telecom tower site surveys across Pakistan. A thorough site survey is the foundation of successful tower deployment, whether for greenfield installations, co-location assessments, or infrastructure upgrades.

The procedures outlined here are based on Pakistan Telecommunication Authority (PTA) regulations, international TIA/EIA-222 tower standards, and over 15 years of experience surveying more than 8,000 tower sites across Pakistan's diverse terrain—from the coastal areas of Karachi to the mountainous regions of Gilgit-Baltistan.

Purpose of Site Survey

A comprehensive tower site survey serves multiple critical objectives:

Verify site suitability for proposed equipment installation
Assess structural capacity for additional antenna loading
Evaluate power availability and backup requirements
Document RF environment and potential interference sources
Identify safety hazards and mitigation requirements
Establish baseline for construction cost estimation
Ensure regulatory compliance with PTA and local authorities

Engineering Disclaimer

The procedures in this guide represent best practices shared for educational purposes. Actual site surveys must be conducted by qualified engineers following agreed terms of engagement, site-specific protocols, and Standard Operating Procedures (SOPs) established between HNL and the client. Engineering decisions must be made by licensed professionals based on actual site conditions.

Survey Types

Different project requirements call for different survey scopes:

Survey Type	Duration	Team Size	When Used
Preliminary Survey	2-4 hours	2 persons	Initial site feasibility assessment
Detailed Survey	1-2 days	3-4 persons	Full engineering assessment for new build
Co-location Survey	4-6 hours	2-3 persons	Adding equipment to existing tower
Upgrade Survey	1 day	3 persons	Capacity expansion or technology upgrade
Audit Survey	4-8 hours	2 persons	Compliance verification and safety audit

2. Pre-Survey Preparation

Thorough preparation before arriving at site significantly improves survey quality and reduces the need for follow-up visits. This chapter covers all preparatory activities that must be completed before field mobilization.

Documentation Gathering

Collect and review the following documents before site visit:

Required Pre-Survey Documents

Site coordinates and access directions
Existing tower drawings (if co-location)
Previous structural analysis reports
Equipment specifications for proposed installation
RF design requirements (antenna heights, azimuths)
Power consumption estimates for new equipment
Landlord contact information and access requirements
Local area map showing nearby structures and roads

Equipment Checklist

Ensure the survey team carries all required equipment:

Equipment/Material	Specification	Quantity	Notes
GPS Device	Sub-meter accuracy	1	For precise coordinates
Laser Range Finder	100m+ range	1	Height measurements
Compass/Clinometer	Digital preferred	1	Azimuth readings
Digital Camera	12MP minimum	1	Documentation photos
Measuring Tape	50m steel tape	2	Ground measurements
Multimeter	True RMS	1	Electrical measurements
Clamp Meter	AC/DC capable	1	Load current readings
Earth Tester	3-pole method	1	Grounding verification
RF Analyzer	Band-specific	1	Interference survey
Safety Equipment	Full PPE set	Per person	Mandatory
Survey Forms	Printed templates	Multiple copies	Backup for digital
Laptop/Tablet	With survey software	1	Data recording

Equipment Calibration

All measuring equipment must have valid calibration certificates. Earth testers and RF analyzers should be calibrated within the last 12 months. Maintain calibration records as part of survey documentation.

Team Composition

A standard detailed site survey team consists of:

Survey Lead

Qualifications:

• Telecom engineering degree
• 3+ years tower survey experience
• Certified tower climber (if climb required)
• Knowledge of PTA regulations

RF Engineer

Qualifications:

• RF/Telecom engineering background
• Experience with spectrum analyzers
• Understanding of propagation models
• Antenna pattern knowledge

Electrical Technician

Qualifications:

• Electrical diploma/certification
• Experience with power systems
• Generator/UPS knowledge
• Safety trained for electrical work

Safety Officer

Qualifications:

• NEBOSH/IOSH certification
• First aid certified
• Rescue training for tower work
• Incident reporting experience

Access Coordination

Coordinate site access at least 48 hours before survey:

Access Coordination Steps

1-2 days before survey

1Contact site landlord/owner to confirm visit date and time
2Obtain gate keys or access codes if required
3Confirm escort requirements for restricted areas (cantonments, airports)
4Notify existing tenants on tower of planned survey activities
5Arrange security clearance for team members if required
6Confirm parking arrangements for survey vehicles
7Obtain emergency contact numbers for site personnel

3. Structural Assessment

Structural assessment determines whether an existing tower can safely support additional equipment or if a new tower meets design specifications. This is a critical safety evaluation that must be conducted methodically.

Tower Type Identification

First, identify the tower type as this determines the assessment approach:

Tower Type	Height Range	Common Use	Key Assessment Points
Greenfield Monopole	20-45m	Urban sites	Foundation condition, pole verticality, baseplate
Self-Supporting Tower (SST)	30-100m	Suburban/rural	Leg members, bracing, foundations, anchors
Guyed Mast	50-150m+	Rural/broadcast	Guy wire tension, anchor blocks, mast sections
Rooftop Tower (RTT)	6-15m	Buildings	Building structural capacity, mounting, waterproofing
Camouflage Tower	15-35m	Urban/sensitive	Concealment integrity, internal structure access

Visual Inspection Procedure

Conduct a systematic visual inspection from ground level before any climbing activities:

Foundation Inspection

Examine the tower foundation for signs of distress:

Cracks in concrete (note location, width, direction)
Exposed reinforcement or anchor bolts
Settlement or tilting visible at base
Standing water or poor drainage around foundation
Soil erosion undermining foundation

Steel Member Inspection

Inspect all visible steel members for:

Corrosion levels (surface rust vs. section loss)
Bent or damaged members
Missing or loose bolts at connections
Paint condition and galvanizing integrity
Weld quality at critical joints

Verticality Check

Measure tower plumbness using theodolite or digital inclinometer:

Acceptable deviation: Maximum 0.25% of tower height
For a 40m tower: Maximum 100mm (10cm) deviation at top
Take readings from at least two perpendicular directions
Document any twist or rotation in tower sections

Critical Safety Issue

If foundation cracking exceeds 3mm width, visible settlement exists, or steel section loss exceeds 10%, immediately flag the site as requiring structural engineering evaluation before any equipment installation. Do not proceed with loading assessment until structural integrity is confirmed.

Loading Assessment

Document all existing equipment on the tower to assess remaining capacity:

Equipment Loading Inventory

Record for each antenna/equipment:

Equipment type and model
Mounting height (AGL)
Physical dimensions (H x W x D)
Weight (with mounting bracket)
Wind load area (EPA)

Azimuth orientation
Tilt angle (if applicable)
Feeder cable size and quantity
Mounting bracket type
Operator/tenant identification

Structural Capacity Calculation

For preliminary capacity assessment, use the following guidelines specific to Pakistan's wind zones:

Pakistan Region	Basic Wind Speed	Design Category	Safety Factor
Coastal (Karachi, Gwadar)	47 m/s (170 km/h)	Severe	1.5
Plain Areas (Punjab, Sindh Interior)	39 m/s (140 km/h)	Moderate	1.4
Northern Areas (KPK, AJK)	44 m/s (158 km/h)	High	1.5
Mountainous (Gilgit, Chitral)	47 m/s (170 km/h)	Severe	1.6

Professional Analysis Required

Field survey loading assessment is for preliminary screening only. Any tower with proposed loading exceeding 70% of original design capacity must undergo formal structural analysis by a licensed structural engineer using current TIA-222-H or equivalent standards.

4. Electrical Evaluation

Electrical evaluation ensures the site can support power requirements for new equipment and meets safety standards. This assessment covers grid connection, backup power, grounding, and surge protection systems.

Grid Power Assessment

Evaluate the main power supply to the site:

Grid Power Evaluation Steps

30-45 minutes

1Verify WAPDA/K-Electric connection and sanctioned load
2Measure incoming voltage (should be 380-420V three-phase)
3Check voltage balance across all three phases (max 5% deviation)
4Record current load on each phase during peak operation
5Inspect main breaker and distribution panel condition
6Verify metering is functional and accessible for reading
7Check power factor (should be above 0.85)
8Document any voltage fluctuation history from site personnel

Parameter	Acceptable Range	Action if Outside Range
Phase Voltage	380-420V	Report to utility, consider voltage stabilizer
Voltage Imbalance	Less than 5%	Balance loads, check connections
Frequency	49.5-50.5 Hz	Report to utility (grid issue)
Power Factor	Greater than 0.85	Install capacitor bank
THD (Harmonics)	Less than 8%	Add harmonic filters

Backup Power Assessment

Assess existing backup power systems and capacity for additional load:

Generator Inspection Checklist

Generator make, model, and rated capacity (kVA)
Current loading (measure with clamp meter)
Fuel type and tank capacity
Auto-start functionality test
Transfer switch condition and rating
Last service date and maintenance records
Fuel consumption rate and autonomy calculation
Exhaust system and noise levels

Battery/UPS Inspection Checklist

UPS make, model, and capacity (kVA)
Battery bank configuration (voltage, Ah)
Battery age and replacement date
Backup time at current load (test or calculate)
Battery room ventilation adequacy
Charging system condition
Individual cell voltage readings (for VRLA banks)

Grounding System Evaluation

Proper grounding is critical for equipment protection and personnel safety. Measure and document:

Earth Resistance Measurement

Using 3-pole fall of potential method:

Tower base earth: Must be less than 5 ohms
Equipment shelter earth: Must be less than 5 ohms
Combined earth system: Must be less than 2 ohms (preferred)
Take readings during dry season for worst-case values

Bonding Verification

Verify equipotential bonding:

Tower legs bonded to earth ring
Equipment racks bonded to master ground bar
Feeder cable shields grounded at both ends
Fence grounded and isolated from tower earth

Pakistan Soil Conditions

Earth resistance values vary significantly across Pakistan. Rocky terrain in northern areas may require chemical earthing or extensive electrode arrays. Coastal areas with high water tables typically achieve lower resistance but require corrosion-resistant electrodes. Always specify soil resistivity testing for new installations.

Surge Protection Audit

Verify lightning and surge protection systems:

Lightning Protection

Air terminals on tower top
Down conductors (minimum 2 paths)
Strike counter (if installed)
Aviation warning lights grounded

Surge Protection Devices

AC SPD at main panel (Type 1+2)
DC SPD at rectifier output
Coaxial SPDs on all feeders
Data line protection on telecom cables

5. RF Survey

The RF survey documents the radio frequency environment at the site, identifies potential interference sources, and validates the proposed antenna configuration. This is essential for network planning and regulatory compliance.

Existing Antenna Documentation

Create a detailed inventory of all antennas on the tower:

Equipment/Material	Specification	Quantity	Notes
Antenna Type	Panel/Omni/Parabolic/Other	-	Identify each
Band/Technology	900/1800/2100/2600 MHz	-	Per operator
Height AGL	Measure with laser	-	Center of antenna
Azimuth	Compass reading	-	All three sectors
Mechanical Tilt	Degrees downtilt	-	Bracket setting
Electrical Tilt	RET setting	-	If accessible

Interference Assessment

Scan the RF environment for potential interference sources:

RF Interference Survey

1-2 hours

1Configure spectrum analyzer for bands of interest
2Scan from ground level in all directions (0°, 90°, 180°, 270°)
3Scan at proposed antenna mounting height (if accessible)
4Identify and log all signals above noise floor
5Note any unusual spurious emissions or interference patterns
6Document nearby RF sources (other towers, broadcast stations, radar)
7Measure ambient noise floor in target bands
8Compare with acceptable interference thresholds

Frequency Band	Typical Use in Pakistan	Interference Threshold
700 MHz	4G/LTE (APT700)	-110 dBm
850 MHz	CDMA legacy	-108 dBm
900 MHz	GSM/2G/4G	-108 dBm
1800 MHz	GSM/4G	-105 dBm
2100 MHz	3G/UMTS	-105 dBm
2300 MHz	4G TDD	-103 dBm
2600 MHz	4G FDD	-103 dBm

Line of Sight Verification

For microwave links, verify clear line of sight to far-end:

LOS Survey Checklist

Confirm far-end coordinates and antenna height
Calculate Fresnel zone clearance requirements
Visual confirmation using binoculars/telescope
Photograph far-end site from proposed mount position
Document any obstructions (buildings, trees, terrain)
Note potential future obstructions (construction, tree growth)
Record atmospheric conditions during survey

Seasonal Considerations

In agricultural areas of Punjab and Sindh, consider seasonal vegetation that may obstruct microwave paths. Sugar cane and wheat crops can grow to 3-4 meters. Design links with adequate fade margin or conduct surveys during peak growth season.

6. Documentation

Comprehensive documentation is the tangible output of the site survey. Proper documentation enables accurate engineering design, cost estimation, and serves as a baseline for future reference.

Photography Requirements

General Site Views

• Site entrance and access road
• Panoramic view (4 directions)
• Tower full height view
• Compound overview
• Surrounding area (500m radius)

Structural Details

• Foundation close-up
• Base section and anchor bolts
• Each tower section joint
• Any damage or corrosion
• Guy wire anchors (if applicable)

Equipment & Electrical

• Main electrical panel
• Generator and fuel tank
• Battery bank/UPS
• Earth bar and connections
• All installed antennas

Survey Report Structure

The final survey report must include the following sections:

Section	Contents	Responsibility
Executive Summary	Key findings, recommendations, go/no-go decision	Survey Lead
Site Information	Location, coordinates, access, landlord details	Survey Lead
Structural Assessment	Tower type, condition, loading, capacity analysis	Survey Lead
Electrical Assessment	Power supply, backup, grounding, protection	Electrical Tech
RF Assessment	Antenna inventory, interference, LOS verification	RF Engineer
Safety Assessment	Hazards identified, mitigation requirements	Safety Officer
Photo Documentation	Indexed photos with annotations	All team members
Checklists	Completed and signed inspection forms	Survey Lead
Recommendations	Required works, estimated costs, timeline	Survey Lead

Report Turnaround

Survey reports should be completed within 5 working days of site visit. For urgent projects, preliminary findings can be communicated within 24 hours with the full report to follow. All reports require technical review before client submission.

7. Safety Considerations

Safety is non-negotiable in all survey activities. This chapter outlines the minimum safety requirements that must be followed during every site survey, regardless of survey type or site conditions.

Mandatory PPE Requirements

Required Personal Protective Equipment

Safety helmet (ANSI Z89.1 rated)
High-visibility vest (Class 2 minimum)
Safety boots (steel toe, EH rated)
Safety glasses (ANSI Z87.1)

Work gloves (task appropriate)
Hearing protection (if generator running)
Sun protection (hat, sunscreen)
First aid kit (team minimum)

Tower Climbing Safety

If tower climbing is required during survey:

Pre-Climb Safety Checklist

15-20 minutes

1Verify climber certification is current (within 12 months)
2Conduct equipment inspection (harness, lanyards, connectors)
3Check weather conditions (no climbing if wind speed exceeds 35 km/h)
4Brief rescue plan and ensure rescue-capable person on ground
5Establish communication method (radio or voice)
6Verify RF hazard status (reduce power if required)
7Complete climb permit documentation
8Identify fall zones and establish exclusion area

RF Radiation Safety

Never climb into RF hazard zones without power reduction coordination. Exposure to high RF levels can cause serious injury. Always verify that all operators have reduced power or that exclusion distances are maintained. Use personal RF monitors when working near active antennas.

Electrical Safety

When conducting electrical assessments:

Electrical Safety Rules

Only qualified personnel may open electrical panels
Use insulated tools rated for working voltage
Never work on live circuits - always isolate first
Test before touch - verify de-energized state
Maintain safe distances from exposed conductors
Use appropriate PPE (insulated gloves, face shield)
Never work alone on electrical systems

Emergency Procedures

All team members must know emergency procedures before survey begins:

Emergency Contacts

Rescue: 1122 (Pakistan Emergency)
Police: 15
Fire: 16
HNL Emergency: Document before survey
Nearest Hospital: Identify before survey

Emergency Actions

1. Ensure scene safety
2. Call for help immediately
3. Provide first aid if trained
4. Preserve evidence
5. Report to HNL safety team

8. Master Checklists

The following checklists should be printed and completed on-site during every survey. Signed checklists must be included as appendices to the survey report.

Pre-Survey Checklist

PRE-SURVEY CHECKLIST

Complete before site mobilization

Site ID: _____________

Date: _____________

Site coordinates and access directions confirmedInit: ___

Existing tower drawings reviewed (if applicable)Init: ___

Equipment specifications received from clientInit: ___

Survey equipment inspected and calibratedInit: ___

Site access coordinated with landlord/operatorInit: ___

Team briefed on scope and safety requirementsInit: ___

PPE available for all team membersInit: ___

Emergency contacts and nearest hospital identifiedInit: ___

Survey Lead Signature

Date

Structural Assessment Checklist

STRUCTURAL ASSESSMENT CHECKLIST

Complete during site survey

Site ID: _____________

Tower Type: _____________

Foundation visual inspection completed - no cracks exceeding 3mmInit: ___

Steel members inspected - no section loss exceeding 10%Init: ___

Bolt connections checked - no missing or loose boltsInit: ___

Tower verticality measured - within 0.25% toleranceInit: ___

Climbing facilities inspected - safe for useInit: ___

All existing equipment inventoried with heights and weightsInit: ___

Guy wires checked (if applicable) - proper tensionInit: ___

Photos taken of all structural elementsInit: ___

Structural Assessment Result:

PASS - Suitable for proposed loadingREFER - Requires structural analysisFAIL - Not suitable

Surveyor Signature

Date

Electrical Assessment Checklist

ELECTRICAL ASSESSMENT CHECKLIST

Complete during site survey

Site ID: _____________

Date: _____________

Grid voltage measured: R-Y: ___V, Y-B: ___V, B-R: ___VInit: ___

Voltage imbalance calculated: ____% (must be less than 5%)Init: ___

Generator capacity: ____kVA, Current load: ____kWInit: ___

Battery backup time tested/calculated: ____ hoursInit: ___

Earth resistance measured: Tower: ____Ω, Shelter: ____ΩInit: ___

Surge protection devices inspected and functionalInit: ___

Available spare capacity identified: ____kWInit: ___

Electrical Assessment Result:

PASS - Adequate for proposed loadUPGRADE - Requires power enhancementFAIL - Major remediation needed

Electrical Technician Signature

Date

Survey Completion Checklist

SURVEY COMPLETION CHECKLIST

Complete before leaving site

Site ID: _____________

Date: _____________

All required photographs captured and backed upInit: ___

GPS coordinates recorded for all key pointsInit: ___

All checklists completed and signedInit: ___

Measurement data verified for accuracyInit: ___

Site secured and landlord notified of departureInit: ___

No equipment or materials left on siteInit: ___

Preliminary findings communicated to project managerInit: ___

Survey Team Sign-Off:

Survey Lead

Name & Signature

RF Engineer

Name & Signature

Electrical Tech

Name & Signature

Document Retention

All completed survey checklists must be retained for a minimum of 7 years as per quality management requirements. Digital copies should be stored in the project document management system within 48 hours of survey completion.

Document Information

Document: Tower Site Survey Checklist

Version: 2.1

Last Updated: December 2024

Author: HNL Engineering Team

Category: Telecom Infrastructure

Related Technical Guides

Telecom Infrastructure

Fiber Optic Installation Guide

Comprehensive procedures for fiber optic cable installation including underground and aerial deployment methods for Pakistan's telecom infrastructure.

Energy & Power Systems

Hybrid Power System Design

Technical guide for designing hybrid power systems combining solar, diesel, and battery storage for off-grid and backup power applications.

Energy & Power Systems

Generator Installation Manual

Step-by-step procedures for installing and commissioning diesel generators from 20kVA to 2000kVA capacity.
